Oem Dahua

NVR videoregistratore videosorveglianza 16 canali 12 MP, per telecamere

NVR videoregistratore videosorveglianza 16 canali 12 MP, per telecamere

Regular price €640,00
Regular price Sale price €640,00
Sale Sold out
Tax included. Shipping calculated at checkout.

Tipo: Videoregistratore

Marca: Oem Dahua

Modello: Nvr

Contattaci per l'acquisto di quantità maggiori rispetto alla disponibilità.


IMPORTANTE: per l'acquisto di maggiori quantità inviare messaggio.


Specifications

General
Main Processor
Quad-core embedded processor
Operating System
Embedded Linux
Video Input
16 channels
Two-way Talk
1 channel input, 1 channel output, RCA
Interoperability
ONVIF 2.4, CGI conformant
Display
Video Output
2 x HDMI, 1 x VGA
Display Resolution
Configurable from 3840 x 2160 to 1024 x 768
Display Split
1/4/8/9/16
OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Recording Resolution
Configurable from 12.0MP (4000 x 3000) to CIF (352 x 288)
Incoming Bandwidth
320Mbps
Video Compression
H.265 / H.264 / MJPEG / MPEG4
Bit Rate
16kbps ~ 20Mbps per channel
Record Modes
Manual / Schedule (Regular [Continuous], Motion Detection, Alarm) / Stop
Record Interval
1~120 min (default: 60 min) / Pre-record: 1~30s / Post-record: 10~300s
Features
Alarm Input / Output
16 channels input / 6 channels relay output (N.O/N.C)
Trigger Events
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer, Screentips
Video Detection
Motion Detection, Motion Zones: 396 (22 x 18), Video Loss & Tampering
Playback Sync
1/4/9/16
Search Modes
Time/Date, Alarm, Motion Detection, Exact Search (to the second), Smart Search
Backup Modes
USB Device / Network / eSATA Device / Internal SATA burner
Network
Ethernet
1 x RJ-45 port (10/100/1000Mbps)
Power over Ethernet
16 ports (IEEE802.3at/af)
Network Functions
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, P2P
Optical Interface
N/A
Max. User Access
128 users
Remote View
iOS (iPhone, iPad) / Android devices / Windows Phone* (limited functionality)
Storage
Internal HDD
4 x SATA ports up to 10TB, max. 40TB HDD capacity
HDD Modes
Single (no RAID compatibility)
USB Interface
3 ports: Rear USB3.0 / Front USB2.0
Auxiliary Inputs
1 x RS232 / 1 x RS485 / 1 x eSATA
Environment
Power Supply
100 ~ 240VAC, 50 ~ 60Hz
Power Consumption
< 17.5W (without HDD)
PoE
Operating Environment
-10 ~ 55°C / 10 ~ 90%RH / 86 ~ 106kpa
Rackmountable
Rackmount Units
Dimensions
Weight
4.65kg (without HDD)
Other
Dimensions / Rack Units
440 x 411 x 76mm / 1.5U
Warranty (Years)

4
